Pocket Door
Rollers

Call Toll Free
(888) 915-5223

pocket door rollers

Questions? visit our FAQ page

Home>    Baldwin>  Pocket Door Locks> rollers

Pocket Door Locks Pocket Door Repair Video Pocket Door Track Kits Pocket Door Guides


all items below and more can now be found on our new site

for complete and updated Selection along with pricing and shopping cart options

e-z guide ball bearing 16576
1 1/4" diameter nylon ball bearing wheel
adjustable steel bracket mounts on top of door
fits E-Z guide
1 roller assembly

To buy this item - visit our new site Hangingdoorhardware.com
e-z guide fixed wheel 16577
1 1/4" diameter nylon ball bearing wheel
diecast housing used as a fixed back roller
fits E-Z guide
1 roller assembly

To buy this item - visit our new site Hangingdoorhardware.com
kennaframe adjustable 161081
1" diameter nylon wheel - steel bracket
adjustable to 5/16" height
fits Kennaframe
1 roller assembly

To buy this item - visit our new site Hangingdoorhardware.com
163190
7/8" diameter nylon wheel - steel bracket
fits Cox
2 roller assemblies

To buy this item - visit our new site Hangingdoorhardware.com
atlas 2 wheel 162168
7/8" diameter tandem nylon wheels - steel bracket
fits Atlas
1 roller assembly

To buy this item - visit our new site Hangingdoorhardware.com
161100
4 wheel carrier - 23/32" diameter nylon wheels, spring loaded
steel bracket
fits Atlas
1 roller assembly

To buy this item - visit our new site Hangingdoorhardware.com
BB 163-208
4 wheel carrier- 7/8" diameter BALL BEARING nylon wheels
15/16" centerline of rollers / 1/4" wide wheels
steel bracket
2 roller assemblies

To buy this item - visit our new site Hangingdoorhardware.com
163-208
4 wheel carrier- 7/8" diameter nylon wheels
15/16" centerline of rollers / 1/4" wide wheels
steel bracket
2 roller assemblies

To buy this item - visit our new site Hangingdoorhardware.com
cox tandom wheel 16208-A
Tandem Wheels, 7/8" round edge nylon wheel
adjustable steel hanger
fits Cox
2 roller assemblies

To buy this item - visit our new site Hangingdoorhardware.com
16497
Tandem Wheels, 7/8" round edge nylon wheel
adjustable steel hanger
fits Acme
2 roller assemblies

To buy this item - visit our new site Hangingdoorhardware.com
dimensions

1125
1" Heavy Duty Ball Bearing roller assembly
with quick connect and easy height adjustment

fits Johnson

To buy this item - visit our new site Hangingdoorhardware.com

dimensions 1025
3/4" Heavy Duty Ball Bearing roller assembly
with quick connect and easy height adjustment

fits Johnson
To buy this item - visit our new site Hangingdoorhardware.com

882T - 190-801

4 Wheel Carrier set
7/8" round edge nylon wheel
adjustable steel hanger
fits National Manufacturing
2 roller assemblies

To buy this item - visit our new site Hangingdoorhardware.com



We offer the wide selection of rollers above.
To check against your roller: match up the screw holes, wheel size, overall bracket dimensions and any other holes or measurements listed from your assembly to the ones above.
In normal circumstances if the dimensions do not match the wheels will not work.

It is also very difficult to guess at a missing wheel based on track profile/size.
If you live in a tract home your neighbor may have the same setup so you can measure from his.

Some wheels are trapped and can not be romoved. The easiest way to remove the old assembly is to cut approx 3-4 inches of track and the end against the wall, this will allow the wheel to be taken out. The piece that was cut out can be screwed back up to complete the track.

We do offer complete units with track from PCHenderson , however, freight will be higher because of UPS limitations on package size. We do have them available for pick up at our location in Orange County California.

We keep a large selection of stock on hand. Most units ship same day via UPSP Prioity Mail and you recieve them in 2-3 days.
Order the items above through our online shopping cart for the fastest service. Larger orders will ship UPS and have a slightly longer shipping time. Next day and Second day shipping options are available at a higher shipping cost.

All returns are subject to a 10% restocking fee, you must call for an RGA before shipping any returns
